Name: 16x25x5 Replacement Air Filters for Honeywell FC100A1029 Air System, Lennox X6672, Carrier EXPXXFIL0016
Brand: Honeywell
Price: 62.99 USD
Availability: InStock

How to Measure Your Filter

Steps 1 & 2

Measuring Length and Width (L x W). (If your filter is not a square, the smallest measurement goes first).

Step 3

Measure the thickness (Depth) of your filter from front to back.

Step 4

Put Your measurements together (L x W x D).

Actual Size

A filter’s true dimensions.

Example: 19.75” x 19.75” x 1”

Nominal Size

Rounded numbers used by manufacturers.

Example 20” x 20” x 1”

View Detailed Instructions

16x25x5 Replacement Air Filters for Honeywell FC100A1029 Air System, Lennox X6672, Carrier EXPXXFIL0016

Save 11%

Select Your MERV Rating:

Clean

MERV 8

Traps: lint, dust, mold spores

["Lint","Dust","Mold Spores"]

Allergy

MERV 11

Traps: pollen, pet dander, smoke, auto emissions

["Pollen","Pet dander","Smoke","Auto emissions"]

Health

MERV 13

Traps: bacteria and virus carriers

[" Bacteria and virus carriers"]

Select the Number of Filters:

[{"id":44484211310838,"title":"MERV 8 \/ 6","option1":"MERV 8","option2":"6","option3":null,"sku":"RDP.HW051625M08-6","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"16x25x5 Replacement Air Filters for Honeywell FC100A1029 Air System, Lennox X6672, Carrier EXPXXFIL0016 - MERV 8 \/ 6","public_title":"MERV 8 \/ 6","options":["MERV 8","6"],"price":17099,"weight":0,"compare_at_price":19199,"inventory_management":"shopify","barcode":"849330092244","requires_selling_plan":false,"selling_plan_allocations":[{"price_adjustments":[{"position":1,"price":17099}],"price":17099,"compare_at_price":17099,"per_delivery_price":17099,"selling_plan_id":2927427830,"selling_plan_group_id":"5cc8c92f63f0a3c97328b1169377a6e42556e025"}],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":44484211146998,"title":"MERV 11 \/ 2","option1":"MERV 11","option2":"2","option3":null,"sku":"RDP.HW051625M11-2","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"16x25x5 Replacement Air Filters for Honeywell FC100A1029 Air System, Lennox X6672, Carrier EXPXXFIL0016 - MERV 11 \/ 2","public_title":"MERV 11 \/ 2","options":["MERV 11","2"],"price":6499,"weight":454,"compare_at_price":7299,"inventory_management":"shopify","barcode":"849330092251","requires_selling_plan":false,"selling_plan_allocations":[{"price_adjustments":[{"position":1,"price":6499}],"price":6499,"compare_at_price":6499,"per_delivery_price":6499,"selling_plan_id":2927427830,"selling_plan_group_id":"5cc8c92f63f0a3c97328b1169377a6e42556e025"}],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":44484211179766,"title":"MERV 13 \/ 2","option1":"MERV 13","option2":"2","option3":null,"sku":"RDP.HW051625M13-2","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"16x25x5 Replacement Air Filters for Honeywell FC100A1029 Air System, Lennox X6672, Carrier EXPXXFIL0016 - MERV 13 \/ 2","public_title":"MERV 13 \/ 2","options":["MERV 13","2"],"price":6999,"weight":454,"compare_at_price":7899,"inventory_management":"shopify","barcode":"849330092268","requires_selling_plan":false,"selling_plan_allocations":[{"price_adjustments":[{"position":1,"price":6999}],"price":6999,"compare_at_price":6999,"per_delivery_price":6999,"selling_plan_id":2927427830,"selling_plan_group_id":"5cc8c92f63f0a3c97328b1169377a6e42556e025"}],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":44484211212534,"title":"MERV 8 \/ 4","option1":"MERV 8","option2":"4","option3":null,"sku":"RDP.HW051625M08-4","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"16x25x5 Replacement Air Filters for Honeywell FC100A1029 Air System, Lennox X6672, Carrier EXPXXFIL0016 - MERV 8 \/ 4","public_title":"MERV 8 \/ 4","options":["MERV 8","4"],"price":11999,"weight":0,"compare_at_price":13499,"inventory_management":"shopify","barcode":"849330092244","requires_selling_plan":false,"selling_plan_allocations":[{"price_adjustments":[{"position":1,"price":11999}],"price":11999,"compare_at_price":11999,"per_delivery_price":11999,"selling_plan_id":2927427830,"selling_plan_group_id":"5cc8c92f63f0a3c97328b1169377a6e42556e025"}],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":44484211245302,"title":"MERV 11 \/ 4","option1":"MERV 11","option2":"4","option3":null,"sku":"RDP.HW051625M11-4","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"16x25x5 Replacement Air Filters for Honeywell FC100A1029 Air System, Lennox X6672, Carrier EXPXXFIL0016 - MERV 11 \/ 4","public_title":"MERV 11 \/ 4","options":["MERV 11","4"],"price":12399,"weight":0,"compare_at_price":13899,"inventory_management":"shopify","barcode":"849330092251","requires_selling_plan":false,"selling_plan_allocations":[{"price_adjustments":[{"position":1,"price":12399}],"price":12399,"compare_at_price":12399,"per_delivery_price":12399,"selling_plan_id":2927427830,"selling_plan_group_id":"5cc8c92f63f0a3c97328b1169377a6e42556e025"}],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":44484211278070,"title":"MERV 13 \/ 4","option1":"MERV 13","option2":"4","option3":null,"sku":"RDP.HW051625M13-4","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"16x25x5 Replacement Air Filters for Honeywell FC100A1029 Air System, Lennox X6672, Carrier EXPXXFIL0016 - MERV 13 \/ 4","public_title":"MERV 13 \/ 4","options":["MERV 13","4"],"price":13299,"weight":0,"compare_at_price":14899,"inventory_management":"shopify","barcode":"849330092268","requires_selling_plan":false,"selling_plan_allocations":[{"price_adjustments":[{"position":1,"price":13299}],"price":13299,"compare_at_price":13299,"per_delivery_price":13299,"selling_plan_id":2927427830,"selling_plan_group_id":"5cc8c92f63f0a3c97328b1169377a6e42556e025"}],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":44484211114230,"title":"MERV 8 \/ 2","option1":"MERV 8","option2":"2","option3":null,"sku":"RDP.HW051625M08-2","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"16x25x5 Replacement Air Filters for Honeywell FC100A1029 Air System, Lennox X6672, Carrier EXPXXFIL0016 - MERV 8 \/ 2","public_title":"MERV 8 \/ 2","options":["MERV 8","2"],"price":6299,"weight":454,"compare_at_price":7099,"inventory_management":"shopify","barcode":"849330092244","requires_selling_plan":false,"selling_plan_allocations":[{"price_adjustments":[{"position":1,"price":6299}],"price":6299,"compare_at_price":6299,"per_delivery_price":6299,"selling_plan_id":2927427830,"selling_plan_group_id":"5cc8c92f63f0a3c97328b1169377a6e42556e025"}],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":44484211343606,"title":"MERV 11 \/ 6","option1":"MERV 11","option2":"6","option3":null,"sku":"RDP.HW051625M11-6","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"16x25x5 Replacement Air Filters for Honeywell FC100A1029 Air System, Lennox X6672, Carrier EXPXXFIL0016 - MERV 11 \/ 6","public_title":"MERV 11 \/ 6","options":["MERV 11","6"],"price":17699,"weight":0,"compare_at_price":19899,"inventory_management":"shopify","barcode":"849330092251","requires_selling_plan":false,"selling_plan_allocations":[{"price_adjustments":[{"position":1,"price":17699}],"price":17699,"compare_at_price":17699,"per_delivery_price":17699,"selling_plan_id":2927427830,"selling_plan_group_id":"5cc8c92f63f0a3c97328b1169377a6e42556e025"}],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":44484211376374,"title":"MERV 13 \/ 6","option1":"MERV 13","option2":"6","option3":null,"sku":"RDP.HW051625M13-6","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"16x25x5 Replacement Air Filters for Honeywell FC100A1029 Air System, Lennox X6672, Carrier EXPXXFIL0016 - MERV 13 \/ 6","public_title":"MERV 13 \/ 6","options":["MERV 13","6"],"price":18999,"weight":0,"compare_at_price":21299,"inventory_management":"shopify","barcode":"849330092268","requires_selling_plan":false,"selling_plan_allocations":[{"price_adjustments":[{"position":1,"price":18999}],"price":18999,"compare_at_price":18999,"per_delivery_price":18999,"selling_plan_id":2927427830,"selling_plan_group_id":"5cc8c92f63f0a3c97328b1169377a6e42556e025"}],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":44484211409142,"title":"MERV 8 \/ 12","option1":"MERV 8","option2":"12","option3":null,"sku":"RDP.HW051625M08-12","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"16x25x5 Replacement Air Filters for Honeywell FC100A1029 Air System, Lennox X6672, Carrier EXPXXFIL0016 - MERV 8 \/ 12","public_title":"MERV 8 \/ 12","options":["MERV 8","12"],"price":32499,"weight":0,"compare_at_price":36399,"inventory_management":"shopify","barcode":"849330092244","requires_selling_plan":false,"selling_plan_allocations":[{"price_adjustments":[{"position":1,"price":32499}],"price":32499,"compare_at_price":32499,"per_delivery_price":32499,"selling_plan_id":2927427830,"selling_plan_group_id":"5cc8c92f63f0a3c97328b1169377a6e42556e025"}],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":44484211441910,"title":"MERV 11 \/ 12","option1":"MERV 11","option2":"12","option3":null,"sku":"RDP.HW051625M11-12","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"16x25x5 Replacement Air Filters for Honeywell FC100A1029 Air System, Lennox X6672, Carrier EXPXXFIL0016 - MERV 11 \/ 12","public_title":"MERV 11 \/ 12","options":["MERV 11","12"],"price":33699,"weight":0,"compare_at_price":37799,"inventory_management":"shopify","barcode":"849330092251","requires_selling_plan":false,"selling_plan_allocations":[{"price_adjustments":[{"position":1,"price":33699}],"price":33699,"compare_at_price":33699,"per_delivery_price":33699,"selling_plan_id":2927427830,"selling_plan_group_id":"5cc8c92f63f0a3c97328b1169377a6e42556e025"}],"quantity_rule":{"min":1,"max":null,"increment":1}},{"id":44484211474678,"title":"MERV 13 \/ 12","option1":"MERV 13","option2":"12","option3":null,"sku":"RDP.HW051625M13-12","requires_shipping":true,"taxable":true,"featured_image":null,"available":true,"name":"16x25x5 Replacement Air Filters for Honeywell FC100A1029 Air System, Lennox X6672, Carrier EXPXXFIL0016 - MERV 13 \/ 12","public_title":"MERV 13 \/ 12","options":["MERV 13","12"],"price":36099,"weight":0,"compare_at_price":40499,"inventory_management":"shopify","barcode":"849330092268","requires_selling_plan":false,"selling_plan_allocations":[{"price_adjustments":[{"position":1,"price":36099}],"price":36099,"compare_at_price":36099,"per_delivery_price":36099,"selling_plan_id":2927427830,"selling_plan_group_id":"5cc8c92f63f0a3c97328b1169377a6e42556e025"}],"quantity_rule":{"min":1,"max":null,"increment":1}}]

About 16x25x5 Replacement Air Filters for Honeywell FC100A1029 Air System, Lennox X6672, Carrier EXPXXFIL0016

Actual Size: 15 7/8"x24 3/4"x4 3/8" Product: RDP.HW051625M08-6 8 Fights: Dust & Pollen

The Aerostar 16x25x5 Replacement Furnace Filter for Honeywell FC100A1029 Air Systems features a multi-model fit design (see Additional Specifications for full model list) and is available in multiple MERV filtration levels to suit your lifestyle and needs.

Air Filter Type: Deep Pleat

FPR Rating: FPR 5

Quality: Dust & Pollen

Captured Particle Size: 3-10 Microns

Material: Deep Pleat

Capacity: High Capacity

MERV Rating: 8

SKU: RDP.HW051625M08-6

MPR Rating: MPR 600

GTIN/UPC: 849330092244

Lead Time: 5 Business Day

MERV 8, MPR 600, FPR 5
Fights lint, dust mites, mold spores, pollen, pet dander, and dust.
Every 6 Months
Qualifies for

Designed to fit housing units accommodating 16x25x4, 16x25x4.5, and 16x25x5 whole house filters

This whole house air filter is designed for residential use. By providing cleaner air, this filter reduces the risk of allergens in the home. It is effective at capturing particles like dust, pollen and mold spores from the air passing through the filter. It is also designed to be effective at attracting and capturing microscopic particles that can carry bacteria and viruses. This filter lasts for up to 12 months before needing replacement.

Replaces brand and part number:

3M Filtrete: Clean Living 600
BDP: FILBBCAR0016, FILBBFT0016, FILBBFTC0016, FILCCCAR0016, FILCCFTC0016, KEAFL0201014, MACPAK16
Bryant: FILBBCAR0016, FILBBFT0016, FILBBFTC0016, FILCCCAR0016, FILCCFTC0016, KEAFL0201014, MACPAK16
Carrier: EZXCAB016, MACA016, MPKA016, FILCAB016, EXPXXFIL0016, EXPXXIMV0016, EXPXXLMC0016, FILBBCAR0016, FILBBFT0016, FILBBFTC0016, FILCCCAR0016, FILCCFTC0016, KEAFL0201014
Day & Night: FILBBCAR0016, FILBBFT0016, FILBBFTC0016, FILCCCAR0016, FILCCFTC0016, KEAFL0201014, MACPAK16
Honeywell: F25, F25F1000, 203719, F35, F35R, F35F1008, FC35A1001, F100, F100F1012, F150, FC100A1026, FC100A1029, FC100C1009, F200, FC200E1029, F25A1043, F25F1042, F35F1008, F100F1012, F150E1026, F200E1029, FC35A1001, FC100A1029, FC200E1029, F50A1074, F50E1158, F50E1174, F50E1281, F50E6074, F50E8054, F50F1073, F50F1099, F55F1011, F58A1018, F300E1019.
Lennox: X0583, X8306, X6672
Payne: FILBBCAR0016, FILBBFT0016, FILBBFTC0016, FILCCCAR0016, FILCCFTC0016, KEAFL0201014, MACPAK16
Totaline: FILBBCAR0016, FILBBFT0016, FILBBFTC0016, FILCCCAR0016, FILCCFTC0016, KEAFL0201014, MACPAK16

Actual Dimensions: 15 7/8" x 24 3/4" x 4 3/8"

MERV 8 pleated filters utilize 100% synthetic media. They help capture airborne particles/allergens between 3-10 microns in size and are an ideal upgrade from standard disposable panel filters.

Dust & Lint
Pet Dander
Dust Mites
Pollen
Lasts up to 12 months

What is a MERV Rating?

MERV ratings let you know the efficiency and level of filtration that an air filter can handle under normal circumstances. The higher the MERV rating, the finer the particles are that are filtered our of the air in your home. Many air filter retailers use MERV or a similar rating to rate their air filters.

About MERV, MPR and FPR Rating

MERV Rating (Minimum Efficiency Reporting Value):

MERV Rating is the primary rating system used in the industry, both domestically and internationally. Established by the American Society of Heating, Refrigerating, and Air Conditioning Engineers, MERV rates a filter’s ability to capture and hold particles and pollutants.

MPR (Micro-Particle Performance Rating):

MPR Rating is a rating system developed by 3M. It rates the manufacturer’s Filtrete product line and their ability to capture airborne particles smaller than 1 micron.

FPR (Filter Performance Rating):

FPR Rating is a rating system developed by The Home Depot for brands sold through their stores, including Honeywell. It utilizes a color code and number scale (4 to 10) that closely resembles the MERV rating.
